Compact 15-LED GU10 Lighting for Range Hood Projects
A replaceable GU10 lamp can simplify servicing in cooker hood and extractor hood applications. This EDEG design combines a standard twist-lock GU10 base with a compact reflector-style body and a visible array of 15 LED light sources.
Confirmed Product Dimensions
The supplied technical drawing provides the following mechanical references:
| Design detail | Reference value |
|---|---|
| LED quantity | 15 LEDs |
| Front diameter | 49.52 mm |
| Overall height | 55.33 mm |
| Reflector-body section | 32.8 mm |
| GU10 base section | 22.53 mm |
| Pin spacing | 10 mm |
Why the GU10 Format Is Useful
The two-pin GU10 base uses a twist-lock connection, allowing the lamp to be installed or replaced without permanently wiring the lamp itself. For appliance manufacturers, this format can support easier assembly and future maintenance when the approved holder, wiring and electrical specification are matched correctly.
15-LED Optical Layout
The front image shows 15 individual LED elements arranged across the reflector face. The reflector-style construction helps direct light toward the cooking surface, while the approximately 50 mm face size fits the familiar compact GU10 form factor used in many lighting assemblies.
Matching Holder and Trim Accessories
The supplied project images also show a GU10 ceramic holder with cable connector and a stainless-steel trim ring marked OPEN and LOCK. These components can support integration into a compatible range hood panel. Holder clearance, trim-ring cutout, cable length, connector type and mounting method should be confirmed against the final appliance drawing.
Compatibility Checklist Before Ordering
- Confirm the required input voltage and frequency.
- Verify the 49.52 mm lamp diameter and 55.33 mm overall depth.
- Check available clearance behind the range hood panel.
- Confirm the GU10 holder, cable connector and trim-ring dimensions.
- Specify the required wattage, color temperature, beam performance and order quantity.
OEM Range Hood Lighting Support
This 15-LED GU10 lamp is intended for evaluation in compatible cooker hood and extractor hood lighting projects. Electrical ratings are not shown in the supplied files, so voltage, wattage and color temperature must be confirmed for the final configuration before production or replacement use.
Send EDEG your installation drawing, electrical requirements, accessory list and target quantity for an OEM compatibility review and quotation.
